MULLION MATE

ADJUSTABLE PARTITION CLOSURE

North Louisiana Forensics Center Window With Mullion Mate

Mullion-Mate is an adjustable partition closure that creates the perfect transition between window mullions and partition walls.

Mullion-Mate is available in two types:

  • Series 30
  • Series 40 Plus
Sound Attenuation (See White Paper):
  • Series 30 - Composite STC = 35 when tested with 35 STC wall
  • Series 40 Plus - Composite STC = 38 when tested with a 65 STC wall
Testing based on ASTM E90-09 (2016) & ASTM E413-16 utilizing 9' x 14' with High STC wall.
Typical Mullion Mate Assembly DWG | DXF | PDF
Typical Mullion Mate Assembly
Videos
Mullion Mate Series 30
Partition Wall to Window Mullion Installation
Live Installation Time Study versus Drywall Construction
Design Features:
  • For vertical junctions between partition walls and window mullions
  • Finished to match mullions
    • Clear anodized, medium or dark bronze anodized
    • Field paintable finish
    • Powder coated in standard or custom colors
  • Factory spring loaded to fit a variety openings
  • Pre-assembled for ease of installation
  • Factory cut to desired height
  • Optional Mullion Mate end cap to finish partition walls
Louisiana Cancer Research Consortium
Series 30 / Series 40 Plus Options

Mullion Mate 3

  • 2-7/8" minimum to 3-15/16" maximum opening

Mullion Mate 4

  • 4" minimum to 4-15/16" maximum opening

Mullion Mate 5

  • 5" minimum to 6-15/16" maximum opening

Mullion Mate 7

  • 7" minimum to 9-3/4" maximum opening

Mullion Mate 9

  • 9" minimum to 13-3/4" maximum opening
Multiple units are pre-assembled or spliced for larger openings and heights taller than 16'.
Mullion Mate 3 Series 30 DWG | DXF | PDF
Mullion Mate 3 Series 30
Mullion Mate 4 Series 30 DWG | DXF | PDF
Mullion Mate 4 Series 30
Mullion Mate 5 Series 30 DWG | DXF | PDF
Mullion Mate 5 Series 30
Mullion Mate 7 Series 30 DWG | DXF | PDF
Mullion Mate 7 Series 30
Mullion Mate 9 Series 30 DWG | DXF | PDF
Mullion Mate 9 Series 30
Mullion Mate Series 30
Mullion Mate Series 30 Specifications
Mullion Mate 3 Series 30 Section Detail
Mullion Mate 4 Series 30 Section Detail
Mullion Mate 5 Series 30 Section Detail
Mullion Mate 7 Series 30 Section Detail
Mullion Mate 9 Series 30 Section Detail
Mullion Mate Series 30 Application Detail
Mullion Mate 3 Series 40 Plus DWG | DXF | PDF
Mullion Mate 3 Series 40 Plus
Mullion Mate 4 Series 40 Plus DWG | DXF | PDF
Mullion Mate 4 Series 40 Plus
Mullion Mate 5 Series 40 Plus DWG | DXF | PDF
Mullion Mate 5 Series 40 Plus
Mullion Mate 7 Series 40 Plus DWG | DXF | PDF
Mullion Mate 7 Series 40 Plus
Mullion Mate 9 Series 40 Plus DWG | DXF | PDF
Mullion Mate 9 Series 40 Plus
Mullion Mate Series 40 Plus
Mullion Mate Series 40 Plus Specifications
Mullion Mate 3 Series 40 Plus Section Detail
Mullion Mate 4 Series 40 Plus Section Detail
Mullion Mate 5 Series 40 Plus Section Detail
Mullion Mate 7 Series 40 Plus Section Detail
Mullion Mate 9 Series 40 Plus Section Detail
Mullion Mate Series 40 Plus Application Detail

Mullion Mate End Caps for Partition Walls create a great transition at the end of the partition wall and is the perfect product to be specified with Mullion Mate Partition closures. Brake formed aluminum shapes can be created for custom sized end wall conditions.

Extruded Mullion Mate End Cap
Literature Specification Details
PDF DOC   TXT   PDF DWG   DXF   PDF

For Flat walled terminations or cased openings.

Extruded Mullion Mate End Caps
Part Number A
MMEC-375 3 3/4"
MMEC-487 4 7/8"
MMEC-600 6"
MMEC-725 7 1/4"
Brake Formed Mullion Mate End Cap
Literature Specification Details
PDF DOC   TXT   PDF DWG   DXF   PDF

For Flat walled terminations or cased openings.

Brake Formed Mullion Mate End Caps
Part Number A
MMECBF-518 5 1/8"
MMECBF-514 5 1/4"
MMECBF-512 5 1/2"
MMECBF-618 6 1/8"
MMECBF-812 8 1/2"

Optional End Cap Sizes with Drywall Contura Profiles

Click on a profile below to view details and downloads.      DWG | DXF | PDF

CA-12-DW

CA-12-DW

CA-10-DW

CA-10-DW

CA-8-DW

CA-8-DW

CA-6-DW

CA-6-DW

CA-4-DW

CA-4-DW

CA-2-DW

CA-2-DW
