Special Shapes

Series 901 Structural Corner Trim

For edge strength. Can be used with any size GPDW. Use as high-strength corner bead.

Literature

Specification

Details

Part #

A

901-SC-375

3/8"

901-SC-1250

1-1/4"

Series 903 Transition

For use with double GPDW Applications. Used to transition with varying wall thicknesses, or to recess or project sections of a wall.

Literature

Specification

Details

Part #

A

903-ET-58

5/8"

Series 904 Reveal Trim

For reveal around columns and curved or straight walls.

Literature

Specification

Details

Part #

A

B

904-RT-12

1/2"

1/2"

Series 905 Pocket Trim

For edge of perimeter curtain pocket for transition from GPDW to suspended ceiling.

Literature

Specification

Details

Part #

905-PT-34

Series 906 Ceiling Trim

For appearance of a ceiling mold. Used to trim off partitions at ceiling height.

Literature

Specification

Details

Part #

A

906-CT-10

1"

Series 907 Hanging Track

For reveal detail at GPDW ceiling or bulkhead. Primarily used as a track for wall hanging. Also see 926 and 961.

Literature

Specification

Details

Part #

907-HT-12

Series 911 End Cap

For flat walled terminations or cased openings.

Literature

Specification

Details

Part #

A

911-EC-375

3-3/4"

911-EC-487

4-7/8"

911-EC-600

6"

911-EC-725

7-1/4"

Series 916 ‘V’ Trim

Used to develop a chiseled stone block effect.

Literature

Specification

Details

Part #

A

916-VT-34
(1/2" or 5/8" GPDW)

3/4"

Series 922 Reveal Top Track with Taping Fin

For top cap or wall terminations. Can be pre-painted black.

Literature

Specification

Details

Part #

A

B

C

D

E

922-TT
375/75

2-1/2"

5/8"

3-7/8"

5/8"

3/4"

922-TT
487/75

3-5/8"

5/8"

5"

1/2"

3/4"

Series 926 Mid Wall Hanging Track

Used for wall hanging. See also 907 and 961.

Literature

Specification

Details

Part #

926-HT-12

Series 927 Fabric Tuck Reveal

Used with welt insert for fabric wall trim. Welt can be fabric wrapped.

Literature

Specification

Details

Part #

927-FR-12

Series 934 Projection Edge Trim

Used with drywall step.
Also see 941 and 947.

Literature

Specification

Details

Part #

934-210-58

Series 935 Projection Wall Reveal

Also see 941 and 947.

Literature

Specification

Details

Part #

935-534-58

Series 936 Projection Corner Reveal Trim

Also see 934, 935, and 937.

Literature

Specification

Details

Part #

936-CR-58

Series 941 Projection Edge Trim

Use with drywall step.

Literature

Specification

Details

Part #

941-278-58

Series 942 Large Hanging Track

Optional hanging clip is available. Also see 926 and 907.

Literature

Specification

Details

Part #

942-HT-12

Series 945 Two Step Outside Corner

Literature

Specification

Details

Part #

A

945-2X-14

1/4"

945-2X-58

5/8"

945-2X-200

2"

Series 946 J Edge Trim

For double rock or wall board termination.

Literature

Specification

Details

Part #

946-JT-45

Series 947 Projection Molding

Can be used as a corner trim. Plants directly on drywall.

Literature

Specification

Details

Part #

947-CM-25

Series 951 Reveal for Panel System

Use to trim edges of 3/8″ prefinished panels mounted to plywood or drywall. Pre-paint black or purchase prefabricated intersections for effect.

Literature

Specification

Details

Part #

951-518-3/8

Series 953 Wall Base

Literature

Specification

Details

Part #

953-840-58R

Series 956 Wall Reveal at Ceiling

Use as reveal transition from wall to drywall ceiling and/or wall to wall.

Literature

Specification

Details

Part #

A

B

956-412-1/2

1/2"

1/2"

Series 961 Hanging Track

Transition from wall to ceiling. Used for wall hangings and pictures. Create reveal by using standard wall angle. Can be factory painted to match ceiling grid.

Literature

Specification

Details

Part #

961-HT-12

Series 963 Decorative Trim

Snap on decorative trim can be pre-painted or color anodized and curved. End caps can also be provided.

*Appearance of part is different than what is shown

Literature

Specification

Details

Part #

A

B

963-034-034

3/4"

3/4"

963-100-012

1"

1/2"

963-100-100

1"

1"

963-200-114

2"

1-1/4"

963-358-250

3-5/8"

2-1/2"

963-400-058

4"

5/8"

963-400-1316*

4"

13/16"

Series 966 Corner Fabric/Vinyl Trim

Use as fabric tuck at corner. Use with 927-FR-12.

Literature

Specification

Details

Part #

966-FT-12

Series 981 Outside Corner

Use corner trim for crisp and exact angles. Use vertically or horizontally.

Literature

Specification

Details

Part #

A

981-120-30

30°

981-120-45

45°

981-120-60

60°

Series 982 Outside Corner

Use corner trim for crisp and exact angles. Use vertically or horizontally.

Literature

Specification

Details

Part #

A

B

982-34-118

118°

3/4"

Series 983 Pocket Mask

Use corner trim for crisp and exact angles. Use vertically or horizontally.

Literature

Specification

Details

Part #

A

983-90-300

3"

983-90-500

5"

Series 985 Ceiling Transition

Hanging reverse trim to transition from drywall to ceiling tile.

Literature

Specification

Details

Part #

A

B

985-HA-3838

3/8"

1/2"
