ALPRO® Acoustical Wall Panels

ALPRO® acoustical wall panels provide an attractive and affordable solution for any space where noise abatement is required. ALPRO® perforated metal wall panels are available in 8 corrugation patterns, finished in your choice of standard or custom color matched powder coat. In typical installations, ALPRO® wall panels are fastened to “Z” furring attached to existing structures to create a cavity filled with acoustical pads. Panels may be lapped for a continuous look or separated to present a reveal. ALPRO® provides perimeter trims finished to accurately match the wall panels.

Features & Benefits

Panel Options

  • Aluminum Panels – Perforated or non-perforated
  • Aluminum panels may be installed in any interior or exterior environment
  • Steel Panels – These panels are recommended for interior applications in potentially high abuse areas (i.e. gymnasiums)

Panel Standards

Pattern

Max. Length

Aluminum
Thickness

Steel Gauge

.032"

26 ga.

24 ga.

22 ga.

A

120"

X

X

X

B

120"

X

X

X

X

C

144"

X

X*

X

X

D

120"

X

X

X

X

E

120"

X

X

X

F

144"*

X

X

X

H

24"

X

X

X

J

144"

X

X

X

X

* Call factory for limitations.

Material Options

  • Aluminum – 0.032″ thickness in stucco-embossed or smooth surface
  • Steel Panels
    • 22, 24 and 26 gauge thickness
    • Smooth surface, G-90 galvanized

Accessories

  • Perimeter options
    • Gordon’s Contura Perimeter Trim
    • Wall angles
  • Acoustical Pads

Corrugation Patterns

Pattern A
Pattern B
Pattern C
Pattern D
Pattern E
Pattern F
Pattern J

Data on Acoustics

Finish Options

AAMA 2604 Powder Coat Finishes Download PDF

AAMA 2605 Powder Coat Finishes Download PDF

Therapeutic Powder Coat Finishes

Antimicrobial Finishes

Perforation Pattern

System Integration

  • Airslots
  • Lighting
  • Sprinklers
  • Penetrations for electrical devices

Green By Design

  • Products contribute to LEED® certification
  • In-House Finishes

Product Data

Pattern A Panel Detail

Pattern B Panel Detail

Pattern C Panel Detail

Pattern D Panel Detail

Pattern F Panel Detail

Pattern H Panel Detail

Pattern J Panel Detail

Curved Wall Panel Isometric Installation (Vertical)

Curved Wall Panel Section Installation (Vertical)

Curved Wall Panel Top View Installation (Vertical)

Straight Wall Panel Isometric Installation (Horizontal)

Straight Wall Panel Section Installation (Horizontal)

Straight Wall Panel Top View Installation (Horizontal)

Straight Wall Panel Isometric Installation (Vertical)

Straight Wall Panel Section Installation (Vertical)

Straight Wall Panel Top View Installation (Vertical)

ALPRO® Wall Panel Specifications

ALPRO® Brochure

Cleaning & Maintenance
